Digital Control Melting Electric Induction Furnace For All Kinds Of Metals

Digital Control Melting Electric Induction Furnace For All Kinds Of Metals
Features Gallery Product Description Request A Quote
Product Name: Induction Melting Machine
Control Method: Full Digital Precision Control
Melting Materail: Stee Or Iron
Key Point: Energy Saving
Voltage: 340V-430V
Warranty: 12 Months
After Sale Service: Online Technical Support, Door To Door Service
Application: Meltingsteel, Iron, Sliver, Gold, Copper And Other Metals.
High Light:

Melting Electric Induction Furnace


DSP Induction Heating Equipment


DSP Electric Induction Furnace

Basic Infomation
Place of Origin: CHINA
Brand Name: GY
Certification: CE, FCC, SGS, ROHS
Model Number: GYM-60KW
Payment & Shipping Terms
Packaging Details: wooden box
Delivery Time: 5-8 workdays
Payment Terms: T/T
Supply Ability: 500 SETS per month
Product Description

Induction Melting Furnace For All Kinds Of Metals, DSP Induction Heating Equipment


Digital Control Melting Electric Induction Furnace For All Kinds Of Metals 0




Smelting is melting solid metal into liquid in a heating furnace and quenching and tempering, which is widely used in industrial production.
Smelting is an important process in casting production, and energy consumption accounts for 50% of the entire casting production. To complete the smelting process, a smelting furnace is essential.

At present, the intermediate frequency smelting furnace produced by GY has the advantages of multi-control mode operation, safety, environmental protection, high efficiency, and stability, and has incomparable advantages in the field of induction heating.

GY currently has induction melting furnaces and vacuum melting furnaces, which are widely used in the melting of various metal products, such as steel, stainless steel, brass, copper, aluminum, aluminum alloy, gold, silver, and other metal materials, and the melting capacity ranges from 3kg-500kg.

Digital Control Melting Electric Induction Furnace For All Kinds Of Metals 1



  • The melting speed is fast, and the real temperature can reach 2000 ℃ ​​with the addition of a thermal insulation jacket.
  • Equipped with programmed temperature control, set the heating or cooling curve according to your process requirements, and the equipment will automatically heat or cool according to this process.
  • With the pouring device, the molten sample can be poured into the prepared ingot mold to pour out the shape of the sample you want.
  • It can be smelted in a variety of atmospheres: in air, in a protective atmosphere, and in a high vacuum. Buy one type of equipment to achieve multiple functions; it can save your cost to the greatest extent.
  • Equipped with a secondary feeding system: it can realize adding other elements during the melting process, which is convenient for you to prepare diversified samples.
  • The furnace body is made of stainless steel with water cooling to ensure that the temperature of the shell is lower than 35 °C and protects personal safety.

Digital Control Melting Electric Induction Furnace For All Kinds Of Metals 2
The parameters of the 60KW Induction Melting Equipment :


Name 60KW Induction Melting Equipment For Smelting Iron, Steel 8KG Application Smelting steel, iron, aluminum, bronze, and other precious metals
Work power 340V-430V Out power 60KW
Model Number GYM-60KW Certificate CE,SGS




Model: GYM-60KW

Max output power: 60KW

Smelting weight of steel, and iron: 30kg

Smelting weight of aluminum, bronze, and other precious metals: 60kg


Specification Smelting weight of steel and iron Smelting weight of aluminum, bronze, and other precious metals
GYM-40KW 20KG 40KG
GYM-60KW 30KG 60KG
GYM-100KW 50KG 100KG
GYM-160KW 100KG 200KG
GYM-200KW 150KG 300KG
GYM-250KW 200KG 400KG

Digital Control Melting Electric Induction Furnace For All Kinds Of Metals 3
induction melting machine, induction melting furnace, induction smelting
induction melting machine, induction melting, melting gold
 Digital Control Melting Electric Induction Furnace For All Kinds Of Metals 6


1. VS resistance heated furnace

  • High heat efficiency, melting fast.
  • Small size, save energy 30%.
  • Resistance or silicon carbide stock is easy to damage.


2. VS Coal, Gas, Diesel furnace

  • Facilitate the adjustment solution composition and temperature, the bubble of foundry less 1/3 to 1/4, reject rate down 1/2 to 2/3, so that cast have a higher mechanical strength;)
  • Reduced the oxidation of burning;
  • Induction melting can melt a scrap of processing and the small pieces because of its electromagnetic stirring effect .reducing the cost of materials. Reduce environmental pollution; noise is far below the towering equipment. The labor intensity of workers and working conditions have been improved;
  • Cast-iron crucible used in Coal and gas furnaces is harmful to the aluminum alloy by increasing impurity. Graphite crucible used in induction melting without such disadvantages.)


3. VS SCR or Frequency Melting Furnace

  • High heat efficiency, melting fast.
  • Small size, save energy by above 20%.
  • The electromagnetic stirring effect is slight so the service life of the crucible is extended.
  • By adjusting the frequency to achieve power regulation, so melting speed is fast, and material elements burning lose less and better energy saving, in particular the heating of stainless steel, copper, silicon, aluminum, and other non-magnetic material, thus reducing the cost of the casting.


Digital Control Melting Electric Induction Furnace For All Kinds Of Metals 7


  • Direct manufacturer: We are an end manufacturer, prices are reasonable, quality can be guaranteed, and we have an after-sales team to ensure the users have no worries about the metal induction melting furnace maintenance cases.


  • Professional technical suggestions: According to the user’s different application cases and different heating sizes, we can customize different metal induction melting furnaces, we support free induction melting heating technical process support, free tests, quick quotation sheet, and face-to-face service.


  • Easy operation and fast delivery: Our metal induction melting furnaces are using digital control plate, and an intelligent one-click start, so the user’s worker can fast get to the machine operation point. The standard metal induction melting furnace can be delivered once you give the order and payment.


  • 24-hour online after-sales service: For each of our metal induction melting furnaces when doing tests in our factory, we will take some videos and pictures to show you how to connect the machines and how to operate, how to maintain the machines. We provide machine full technical support service when you meet some problems can call us or leave a message to us. Our team will contact you faster.
